Description
6 Channel Class D DSP Amplifier
- CHANNEL CONFIGURATION
- 4.1ch, 6ch
- HIGH PASS FILTER
- Variable: FRONT (500-4 kHz), REAR (50-500 Hz)
- HIGH-PASS FILTER SLOPE
- 12 dB/oct
- LOW PASS FILTER
- Variable: REAR (500-4 kHz), SUBWOOFER (50-500 Hz)
- LOW-PASS FILTER SLOPE
- 12 dB/oct
CTA Rated Output Power
- 4 OHMS
- 45 W × 4 (FRONT/REAR), 90 W × 2 (SUBWOOFER)
- 4 OHMS — BTL (BRIDGE-TIED LOAD)
- 350 W (SUBWOOFER) at 1 kHz
- 2 OHMS
- 175W × 2 (SUB) at 1 kHz, 600 W × 1 (SUBWOOFER bridged) at 1 kHz
Rated Output Power (14.4V, 20Hz-20kHz)
- 4 OHMS
- 45 W × 4 (FRONT/REAR), 90 W × 2 (SUBWOOFER)
- 4 OHMS — BTL (BRIDGE-TIED LOAD)
- 350 W (SUBWOOFER) at 1 kHz
- 2 OHMS
- 175 W × 2 (SUBWOOFER) at 1 kHz, 600 W × 1 (SUBWOOFER bridged) at 1 kHz
Maximum Output Power (1 kHz)
- MAX. CHANNEL CONFIGURATION AT 4 OHMS BTL (BRIDGE-TIED LOAD)
- 600 W (SUB)
- MAX. CHANNEL POWER CONFIGURATION AT 2 OHMS
- 300 W × 2 (SUB), 1100 W × 1 (SUBWOOFER bridged)
- MAX. CHANNEL OUTPUT POWER CONFIGURATION AT 4 OHM
- 100 W×4 (FRONT/REAR), 200 W×2 (SUBWOOFER)
General Features
- FREQUENCY RESPONSE
- 20-20 kHz (FRONT/REAR) 20-10 kHz (SUBWOOFER)
- TOLERANCE
- +0.5/-3 dB
- SIGNAL TO NOISE RATIO
- Rated Output: 100 dB/CTA Rated Output: 83 dBA (FRONT/REAR), 80 dBA (SUBWOOFER)
- TOTAL HARMONIC DISTORTION AT 1 KHZ (%)
- Less than 0.08%
Details
- INPUT
- Line In/High Level (Speaker Level) Input
- MOSFET
- Output Stage/Power Supply
- SUBSONIC HIGH PASS FILTER
- No
- BASS BOOST: FREQUENCY (0 - 10 DB)
- Yes
- LINE IN: INPUT SENSITIVITY
- 0.3-6 V (6ch input mode only)
- GOLD PLATED CONNECTORS
- Yes
- CURRENT DRAIN (A) - RATED OUTPUT POWER AT 4 OHM
- 36 A
DSP Functions with Sony l Music Center App
- TIME ALIGNMENT
- Yes (4.1ch)
- EQUALIZER
- Yes (10-band)
- BALANCE/FADER
- Yes
Bluetooth® Specifications
- VERSION
- 3.0
- SECURE SIMPLE PAIRING
- Yes
- PROFILE
- A2DP, AVRCP
Bluetooth® General Features
- VOICE CONTROL
- No
- MICROPHONE
- No
- DEVICE NAME
- XM-GS6DSP
- AUTO-PAIRING FOR IOS DEVICES
- No
- SONY | MUSIC CENTER (IOS)
- Yes
- SONY | MUSIC CENTER (ANDROID™)
- Yes
- SIRI EYES FREE MODE
- No
