Description
The “c” revisions further refine these drivers with improvements to extend the low frequency midbass output using a longer voice coil winding with copper clad aluminum wire, longer excursion 1⁄2 roll surround and a new cast frame basket allowing larger diameter spiders. The Xmax is increased and the midbass frequency range is broadened while upper mids are smooth and relaxed.
The VO-W woofers feature performance refinements like large diameter voice coils, high-energy Cnc machined motors, cast frames, and the unique ability to thread on our VO-CT compression tweeters and horn for coaxial applications.
Features
-
2.5” VCD
-
Threaded back plate for compression driver mounting
-
New cast aluminum frame
-
8mm Xmax, 30mm suspension travel
-
½ roll surround
-
Poly-cotton spider
-
CCA coil wire
-
Shorting ring motor
-
400 RMS, 800 peak
General Specifications
VO-W8c: 400W to 800W – 8 Inch PA Midwoofer
Speaker Size (In): | 8 |
Watts RMS: | 400 |
Watts Peak: | 800 |
Impedance: | S2 |
Frequency Response (Hz): | 60 - 8k |
Fs (Hz): | 60 |
Qms: | 2.169 |
Qes: | 0.645 |
Qts: | 0.497 |
Vas (Liters): | 25.59 |
dBSPL: | 95 |
Xmax (MM): | 8 |
Mounting Diameter (In): | 7 3/8 |
Mounting Diameter (MM): | 187.3 |
Mounting Depth (In): | 3.75 |
Mounting Depth (MM): | 96 |
Price (USD): | 159 each |
