5 INCH LIFT KIT CHEVY/GMC 1500 (14-18)


Price:
Sale price$1,099.95

Description

OVERVIEW

What better way to deck out that brand new 2014-up GM 1500 you worked so hard for than with the aggressive stance and jaw-dropping ride height of Rough Country's brand-new 5-inch Suspension Lift for 2014 Chevy / GMC 1500 Pickups? This massive lift is designed to retain your stock track width! This affords your truck the ability to run up to an impressive 33-inch tire on factory 20-inch wheels, and gives you a nearly limitless choice in aftermarket wheels and tires that other kits just can't fit.

This kit ships with EVERYTHING you need to give your new truck the aggressive stance and capabilities it deserves; Stout upper strut spacers, a beefy front and rear skid plate, our Heavy Duty Front and Rear Crossmembers, and a set of differential and sway-bar drop brackets - all designed by our in-house Research and Development team with 100% laser-cut materials for the best possible fit on your vehicle.

Also included are a set of our Nitrogen charged N3 Shocks! Offering the best in balanced performance for on and off-road use, these shocks feature a 10-stage velocity sensitive valving custom tuned for this specific application. That means these shocks are specifically valved for use with this vehicle and lift combo, giving you unparalleled performance for any driving situation.

FEATURES

  • Increased ground clearance.
  • Maintains factory track width.
  • Can run factory 20-inch wheels.
  • Fabricated blocks are stronger and offer a longer lifespan than cast blocks.

SPECIFICATIONS

  • Brand: Rough Country
  • Est. Install Time: 8-10 hours

OPTIONAL N3 LOADED STRUTS

  • Includes pre-loaded coil
  • Maintains smooth, factory-like ride
  • Increased ground clearance
  • Engineered for lifted applications
  • Infinitely Variable Damping
  • Leak-proof piston seal
  • Massive 1 3/8in Bore
  • Silver powder coat finish
  • 3-year Manufacturer's Warranty
  •

    OPTIONAL V2 MONOTUBE SHOCKS

  • Monotube design
  • Internal floating piston
  • Nitrogen-charged
  • 46mm high-flow piston
  • Fast heat dissipation
  • 36kN Tensile Strength
  • Mounts inverted
  • T6061 brushed aluminum body
  • 3-year Manufacturer's Warranty
  •

    NOTES - IMPORTANT

    • Requires cutting and drilling.
    • Does NOT fit Hybrid eAssist models.
    • Does NOT fit GMC Denali models with Magnetic Ride Control.
    • If wider than 33x12.50 tires are used, offset wheels will be required and trimming may be required.
    • If truck is equipped with a mass damper on the front differential, the damper must be removed.

    VEHICLE FITMENT

    YEARS DRIVE MAKE MODEL
    2014-2018 4WD Chevy Silverado 1500
    2014-2018 4WD GMC Sierra 1500


    RECOMMENDED TIRES & WHEELS

    TIRE WHEEL BOLT PATTERN OFFSET NOTE
    295/70R17 Factory 17 6x5.5 - -
    295/55R20 Factory 20 6x5.5 - 0.25 Spacer
    285/65R18 Factory 18 6x5.5 - -
    33x12.50R17 17x8.5 6x5.5 +0 -
    285/70R17 17x8.5 6x5.5 +0 -
    33x12.50R17 17x8.5 6x5.5 +1 -
    33x12.50R17 17x9 6x5.5 +0 -
    285/70R17 17x9 6x5.5 +0 -
    33x12.50R17 17x9 6x5.5 +1 -
    285/70R17 17x9 6x5.5 +1 -
    33x12.50R17 17x9 6x5.5 +12 -
    305/70R17 17x9 6x5.5 +12 -
    33x12.50R17 17x9 6x5.5 +18 -
    305/70R17 17x9 6x5.5 +18 -
    285/70R17 17x9 6x5.5 +18 -
    33x12.50R18 18x8.5 6x5.5 +0 -
    33x12.50R18 18x8.5 6x5.5 +1 -
    33x12.50R18 18x9 6x5.5 +0 -
    285/65R18 18x9 6x5.5 +0 -
    33x12.50R18 18x9 6x5.5 +1 -
    285/65R18 18x9 6x5.5 +1 -
    33x12.50R18 18x9 6x5.5 +12 -
    305/65R18 18x9 6x5.5 +12 -
    33x12.50R18 18x9 6x5.5 +18 -
    305/65R18 18x9 6x5.5 +18 -
    285/65R18 18x9 6x5.5 +18 -
    285/65R18 18x9 6x5.5 +19 -
    285/65R18 18x9 6x5.5 +20 -
    33x12.50R20 20x9 6x5.5 +0 -
    305/55R20 20x9 6x5.5 +0 -
    295/60R20 20x9 6x5.5 +0 -
    33x12.50R20 20x9 6x5.5 +1 -
    305/55R20 20x9 6x5.5 +1 -
    295/60R20 20x9 6x5.5 +1 -
    33x12.50R20 20x9 6x5.5 +12 -
    305/55R20 20x9 6x5.5 +12 -
    33x12.50R20 20x9 6x5.5 +18 -
    305/55R20 20x9 6x5.5 +18 -
    295/60R20 20x9 6x5.5 +18 -
    33x12.50R20 20x9 6x5.5 +20 -
    305/55R20 20x9 6x5.5 +20 -
    295/60R20 20x9 6x5.5 +20 -
    33x12.50R20 20x10 6x5.5 -19 Minor Trimming
    305/55R20 20x10 6x5.5 -19 Minor Trimming
    295/60R20 20x10 6x5.5 -19 Trimming Required
    33x12.50R20 20x10 6x5.5 -18 Minor Trimming
    305/55R20 20x10 6x5.5 -18 Minor Trimming
    295/60R20 20x10 6x5.5 -18 Trimming Required
    33x12.50R22 22x10 6x5.5 -19 Minor Trimming
